ELEGOO Standard Green Resin

Description

ELEGOO Standard Green Resin is a high-precision 405 nm UV-curing photopolymer designed for LCD/DLP/MSLA resin 3D printers. It delivers excellent detail, smooth surface finish, and consistent dimensional accuracy with a vivid green colour. This resin is ideal for miniatures, prototypes, display models, figurines, and general-purpose printing where good aesthetics and performance are needed.

Specifications

General

• Resin Type: Standard UV-curable photopolymer

• Colour: Green

• Typical Bottle Size: 1 kg

• Printer Compatibility: LCD, DLP, MSLA 3D printers using 405 nm UV light

Physical & Mechanical Properties

• Viscosity (25 °C): ~150–200 mPa·s

• Shrinkage: ~7% (low shrinkage for good accuracy)

• Hardness (cured): ~84 Shore D

• Liquid Density: ~1.10 g/cm³ (approx.)

• Solid Density: ~1.19 g/cm³ (approx.)

• Tensile Strength: ~36–53 MPa (approx.)

• Flexural Strength: ~59–70 MPa (approx.)

• Elongation at Break: ~14% (approx.)

• Shelf Life: Around 2 years if stored sealed and cool

Printing & Performance

• Curing Wavelength: 405 nm UV

• Typical Exposure Time: 6–10 seconds per layer (varies by printer/settings)

• Surface Finish: Smooth with strong detail reproduction

• Print Stability: Good fluidity and layer consistency

• Odor: Mild, low-odor formulation

Applications

• Miniatures and figurines

• Prototypes and concept models

• Display parts and artistic prints

• Functional small parts

• General hobby resin printing
